Quick Details:
| Description | Model No | Part Number |
| 7 Pin, Male Insert, Crimp Termination | HD-007-MC | 09210073031 |
| 7 Pin, Female Insert, Crimp Termination | HD-007-FC | 09210073131 |
| Top Entry Hood with PG11 | H3A-TE-2B-PG11 | 09200031440 |
| Bottom Open Housing-1 Lever | H3A-BK-1L | 09200030301 |
| PG11 Cable Gland | PG11 | |
Features
1. The insert material is made by PC with glass fibre reinforced.
2. The insulation resistance of insert is more than 1010Ω
3. The Flammability is V0 according to UL94 standard.
4. The contact material is made by Copper Alloy.
5. The contact plating is silver with 3μm thickness
6. The contact resistance is less than 3mΩ
7. The working time is more than 500 mating cycles.
8. The Max working temperature is 125°C
9. The min. working temperature is -40°C
10. The max working current is 10A
11. The max working voltage is 250V
12. The wire gauge from 0.14 to 2.5mm² (AWG 26-14)
13. The protect degree is IP65
14. The locking lever on housing is made by stainless steel
15. The colour of housing is Grey or others.
16. The seal material of Housing is NBR
FAQ:
Q: Why ZJHK price is competitive with good quality?
A: We have been manufacturing heavy dudty connector 7 years and know the market well. Only competitive price can open the market and only good quality can get more orders.
Q: Can we order many different models in a small qty?
A: Yes, we have plenty of stock. And we can delivery by DHL / TNT/ Fedex for small order. Small order is no problem.
Q: Can I ask for a complete set packing with plastic wrapping?
A: Yes, we can assembly all parts together and delivery in a set.
Q: Can I make order with my brand?
A: Yes, we can laser print your brand when the qty reach 100pcs.
Q: What is deivery time when I make payment?
A: For small order, we can finish delivery with 24 hours. For Bulk order, 5~7 days is enough.
Q: How to solve if I meet quality problem?
A: For small order, we will return the money to you, For bulk order, we will return order by sea. We will pay everything.
Q: Are you seeking agent for distributing your brand in market?
A: Yes, welcome to discuss more and visit our factory.
Q: Can I visit your factory?
A: Welcomed to visit our factory in Yueqing city, Zhejiang Province. It is our pleasure to show you around our production line and discuss face to face.
